UL Listed Phenolic Moulding Compound Black Color for Injection Heat
Resistance Parts
Product description
Phenolic moulding compound(PMC) are produced with with heated
rollers or extruders.
Treatment of a mixture of phenolic novolac
resin,hexamethylenetetramine, fillers and
additives leads to an intermediate, the actual moulding material.
The polycondensation is
driven so far that the moulding material in the final molding step
can still flow, but so that
the final cross-linking occurs very quickly. Especially important
processing properties are
good flow characteristics and rapid curing.
Used under the upper temperature limit of 250℃ and the upper
voltage limit of 220V
Suitable for handles and knob of electric oven and top grade pan,
coil holders
☆ Good Fluidity
☆ Rapid Curing
☆ Excellent Heat Resistance
Specification:
| Physical properties | Typical value | Unit | Standard |
| Density | 1.5 | g/cm3 | ISO1183 |
| Apparent Density | 0.5 | g/cm3 | ISO60 |
| Moulding Shrinkage | 0.9 | % | ISO2557 |
| Water absorbency(24h / 23°C) | 20 | mg | ISO62 |
| Thermal properties | | | |
| Temperature of deflection under load | 140 | ℃ | ISO75-2 |
| Temperature resistance | 180 | ℃ | DIN44904 |
| Mechanical properties | | | |
| Flexural strength | 80 | Mpa | ISO178 |
| Charpy Impact strength | 1.55 | KJ/m2 | ISO179-1 |
| Charpy notched Impact strength | 6.5 | KJ/m2 | ISO179-1 |
| Electrical properties | | | |
| Electrical strength | 10 | KV/mm | IEC60243-1 |
| Insulation resistance | 1010 | ohm | IEC60167 |
| Surface resistivity | 1012 | ohm | IEC60093 |
| Volume resistivity | 1012 | ohm*cm | IEC60093 |
| Dissipation factor(1MHz) tanδ | 0.1 | - | IEC60250 |
| Proof Tracking Index | 150 | - | IEC60112
|
Packing&Storage
the package is in 25KGS paper-plastics bag
The storage life of this product is 12 months in a cool and dry
place in original closed bags
FAQ
Q1:Are you a trader or manufactuer?
Established in 1993, located in Wangdian town,Jiaxing City, 100kms
far from Shanghai, JIAMIN are one of excellent manufacturers of
moulding compounds in China, with annual capacity of 30,000 tons.
We produce different quality moulding compounds for various uses,
from household handles to electric appliances, from meters parts to
automotive parts. Backed by decades of experience, we are able to
help you shape a better product at saving cost.
We have been working under ISO 9001 management system, ISO14001
environment management systems since 2008.
JIAXING HONING IMPORT&EXPORT CO.,LTD is our exclusive sales
agent for the oversea market. Our moulding compounds have been sold
all over China domestic market and oversea market. Most of our
moulding compounds are certified by UL94 ,tested by SGS according
to RoHS.
Our advantage:
R&D team offer Complete technical support
a long-term and reliable supplier
Superior-quality materials offered at competitive prices
